Ceph in K8s

In this note, I cover the details that I have uncovered thus far with rook and ceph. Ceph is a distributed filesystem that provides persistent storage, S3-like object store and NFS support in one happy container. Ceph can be quite difficult to install the first couple times. Rook is intended to make deploying Ceph much easier.

Unfortunately, Ceph’s resource requirements exceed that of my little home lab, which consists of four systems with four cores and sixteen gigs of ram each. I managed to get a quick glance at prometheus just before the eviction storm and saw that a whopping 72 pods were spun up.

Clearly exploring topic in depth will have to wait until I add more mores, preferably with more ram and CPU.


Installation involves installing two helm charts; helm-rook to install the rook operator, and helm-rook-ceph, which sets up a cephcluster object among other components.

Rook operator

This installs the rook operator, which watches for the creation of the Ceph related custom resource definitions that it provices and actaully creates them.

helm repo add rook-release https://charts.rook.io/release
# Note: --set "enableDiscoveryDaemon=true" might be necessary if you want
# want to set node definitions in cephclusters

helm install --create-namespace --namespace rook-ceph rook-ceph \
  rook-release/rook-ceph  --set "enableDiscoveryDaemon=true"

# This will start you off with the rook operator and one discover pod
# per node

~/code/linuxguru$ k get pods -n rook-ceph
NAME                                  READY   STATUS    RESTARTS   AGE
rook-ceph-operator-559cbcdf67-x28sb   1/1     Running   0          20s
rook-discover-4kmxq                   1/1     Running   0          16s
rook-discover-86l8b                   1/1     Running   0          16s
rook-discover-cp97c                   1/1     Running   0          16s
rook-discover-k9lx9                   1/1     Running   0          16s

Rook-Ceph cluster

This helm chart creates a pile of ceph custom resource definitions that are picked up by the rook operator above.

helm install --create-namespace --namespace rook-ceph rook-ceph-cluster \
  --set operatorNamespace=rook-ceph rook-release/rook-ceph-cluster

~/code/linuxguru$ k get cephcluster -A -w
rook-ceph   rook-ceph   /var/lib/rook     3          90s   Progressing   Configuring Ceph Mons
rook-ceph   rook-ceph   /var/lib/rook     3          98s   Progressing   Configuring Ceph Mgr(s)
rook-ceph   rook-ceph   /var/lib/rook     3          2m8s   Progressing   Configuring Ceph OSDs
rook-ceph   rook-ceph   /var/lib/rook     3          4m20s   Ready         Cluster created successfully
rook-ceph   rook-ceph   /var/lib/rook     3          4m33s   Ready         Cluster created successfully   HEALTH_WARN

After a few minutes, the cluster is up. In my case, the cluster is unhealhty becuase I do not have any volumes attached to the cluster and LVM volumes are not automatically added. To fix this, I add the nodes and volumes manually, which I discuss below under Configuration


LVM Volumes

Most of the documentation that I came across seems to indicate that LVM volumes with rook-ceph are problematic. Ceph itself can handle LVM volumes, but currently Rook intentionally skips LVM volumes. I was able to use LVM volumes by adding them manually in the ceph cluster It appears that this pull request intentionally disabled automatic adding of logical volumes to “avoid unwanted LV consumption on upgrade.”

apiVersion: ceph.rook.io/v1
kind: CephCluster
    useAllDevices: false  [originally true]
    useAllNodes: false [ originally true]
    - name: k8sn1
      - name: dm-1
    - name: k8sn2
      - name: dm-1
    - name: k8sn3
      - name: dm-1
    - name: k8smaster.vn.linuxguru.net
      - name: dm-1


Ceph does not go down without a fight. You’ll need to do 4 things to return to a pristine state:

Tear down helm

First, lets tear down helm

  1. helm delete rook-ceph-cluster -n rook-ceph
  2. helm delete rook-ceph -n rook-ceph

The rook-ceph namespace wont go away

Finalizers are put into the cephcluster, secret and configmap objects to protect ceph. We’ll need to remove those finalizers before helm will be able to delete the rook-ceph deployment

The error for the namesapce will look like this:

~$ k describe namespace rook-ceph
Name:         rook-ceph
Labels:       kubernetes.io/metadata.name=rook-ceph
Annotations:  <none>
Status:       Terminating
 Type        Status  LastTransitionTime  Reason      Message
 ----        ------  ------------------  ------      -------
 Namespace   True    09 Feb  13:21:16    Some        Some content in the namespace has finalizers remaining:
 Finalizers                              Finalizers  cephblockpool.ceph.rook.io in 1 resource instances,
 Remaining                               Remain      cephobjectstore.ceph.rook.io in 1 resource instances

You can use the following command to find all of the stuck objects and delete them:

kubectl api-resources --verbs=list --namespaced -o name | xargs -n 1 kubectl get --show-kind --ignore-not-found -n rook-ceph

Edit each one of the objects listed and remove their finalizers

For example, do a kubectl get cephblockpool -n rook-ceph, which will show the remaining block pool. kubectl edit that, remove the Finalizers stanza, and you’re good to go.

Clean up nodes

Rook and Ceph leave stuff the nodes that will get in the way if you try to reinstall them later. New builds will fail to work if you forget to clean this first. This includes any masters for which you have removed the noschedule taint!

These actions have to performed on all nodes:

  1. rm -rf /var/lib/rook
  2. For any block device used by ceph: dd if=/dev/zero of=/dev/DEVICE bs=4096 count=10240

For me, that looks like:

for x in k8smaster k8sn1 k8sn2 k8sn3; do
   ssh $x "sudo rm -rf /var/lib/rook";
   ssh $x "sudo dd if=/dev/zero of=/dev/dm-1 bs=4096 count=10240";

Loose Notes
